MAST: Three Stage | STK# 1638 | POSTED: 10/20/2026 | CAPACITY: 4500
2022 Crown RM6025-45
2022 Crown RM6025-45 Electric Narrow Aisle Reach Truck. This used 2022 Crown RM6025-45 is a stand-up, single-reach electric forklift for narrow-aisle warehouse work.
Product Information
Condition
Used
Year
2022
Manufacturer
Crown
Model #
RM6025-45
Subcategory
Electric Narrow Aisle Single Reach
Type
Forklift
Capacity
4500
Mast
Three Stage
Mast Spec
107/240
Fuel
Electric
Attachment
Sideshifter
Valves
Standard Valves & Hosing
Side Shifter
Yes
Hours
4056
Serial #
NA
To Company
Illinois Industrial Equipment
Stock #
1638
Forklift
2022 Electric Crown RM6025-45
Price
CALL
Specifications
Model
- Model NumberRM6025-45
- ManufacturerCrown
General Information
- TypeForklift
- SubtypeElectric Narrow Aisle Single Reach
- Fuel TypeElectric
Dimensions
- Lift Height240 inches
- Mast Height107 inches collapsed
- Overall Height288 inches extended
- Inside Width34 to 50 inches
- Wheelbase60.5 to 64.9 inches
- Machine Length56 to 60.4 inches head length
Performance
- Load Capacity4,500 lbs
- Travel Speed8.0 / 7.2 mph
- Lift Speed160 / 95 fpm
- Load Center24 inches
Powertrain
- Power Voltage36 Volts
- Power TypeAC Electric
- Service BrakeElectric Release
Chassis
- Tire TypePolyurethane
- Drive Tire13x5.5 inches
- Rear Tire8x4 inches caster
Forks
- Fork Length36 inches standard
- Fork Width4 inches
- Fork Thickness1.75 inches
Battery
- Battery TypeReconditioned
- Battery IncludedCharger included
2022 Crown RM6025-45
2022 Crown RM6025-45 Electric Narrow Aisle Reach Truck. This used 2022 Crown RM6025-45 is a stand-up, single-reach electric forklift for narrow-aisle warehouse work. The dealer includes a reconditioned battery and charger, and the truck has new wheels. It is in University Park, IL (60484), stock 1638, showing 4,056 hours.
Capacity is 4,500 lb at a 24-inch load center. The yard lists a three-stage mast, spec 107/240. On the Crown RM 6025 mast chart, that spec is a 240-inch lift height, a 107-inch collapsed height, and a 288-inch extended height, with about 59 inches of free lift. A sideshifter with standard valves and hosing is included.
Crown rates the RM 6025 series at 36 volts. Published travel speed is 8.0 mph empty and 7.2 mph loaded with the power unit leading, and published lift speed is 160 fpm empty or 95 fpm at 4,500 lb. Head length with sideshift is about 56 to 60.4 inches, and wheelbase is about 60.5 to 64.9 inches, depending on battery compartment. Standard forks are 36 x 4 x 1.75 inches. The series chart lists a 13x5.5 drive tire and an 8x4 caster tire. This unit has new wheels, so confirm tire size, forks, and battery compartment at the yard before you buy.
Frequently asked questions
Is the 2022 Crown RM6025-45 still available?
Yes, this unit is listed as available in University Park, IL. Call 708-358-6555 to confirm and schedule delivery.
Do you deliver this forklift nationwide?
Yes. Budget Forklifts arranges nationwide delivery from University Park, Illinois.
Can I inspect the forklift before buying?
Yes. Visit 2400 University Pkwy, University Park, IL 60484 or request photos, hours, and a walkaround by calling 708-358-6555.
